Easy external installation, no need to work inside the tank: The Philippi DSW is a float switch for side mounting on diesel and petrol tanks on board. An externally tightened sealing ring makes installation a one-person job, even for retrofitting.
Tip: Make sure that the tank wall thickness is no more than 5 mm and that the filling pressure is low – the DSW is explicitly designed only for low filling pressure. The DSW is not suitable for water tanks.
Couldn't load pickup availability
brand:
philippi
Availability:
Low stock
SKU:
OB-BB-089300019
Product group:
category:
electrical system
Regular price
€21,75
Regular price
Sale price
€21,75
- Side mounting from the outside – no lock nut required from the inside
- Externally tightened sealing ring for quick, low-tool retrofitting
- Flexible: opens or closes depending on the installation position with rising or falling fluid levels
- Suitable for diesel and gasoline
- Can be combined with Philippi Panel FAF for a full holding tank indicator
| Type | Float switch, side mount |
|---|---|
| Suitable media | Diesel, petrol (not suitable for water) |
| Mounting hole | ø 22–24 mm |
| Sealing width | 12 mm |
| Max. wall thickness | 5 mm |
| Filling pressure | Only suitable for low filling pressure |
| Switching current max. | 0.5 A |
| Compatibility | Philippi Panel FAF (Faecal tank full indicator) |
