Philippi DC On/Off Rocker Switch 2-pole 6A
Regular price
€26,99
Regular price
Sale price
€26,99
Unit price
per
Tax included.
Switching and protecting in one: This two-pole rocker switch from Philippi not only interrupts the circuit at the push of a button, but also trips automatically in case of overload – a real added value in onboard operation. It is part of the Philippi Series 200 and integrates seamlessly into existing control panels of this series.
Tip: When installing into a Philippi Series 200 control panel, ensure the correct device width of 29.5 mm – the cutout must be exactly 26.3 × 34.2 mm for the switch to sit snugly and without wobbling.
Couldn't load pickup availability
brand:
philippi
Availability:
Low stock
SKU:
OB-BB-131312006
Product group:
category:
electrical system
Regular price
€26,99
Regular price
Sale price
€26,99
- Double-pole – simultaneously disconnects positive and negative conductors for safe isolation in DC networks
- Integrated overcurrent protection function – protects the circuit without an additional fuse
- Rated current 6 A, adjustable from 0.1 to 16 A – suitable for many on-board consumers
- Compact design for installation cut-out 26.3 × 34.2 mm – fits in Philippi Series 200 switch panels
- Rated voltage up to DC 30 V – suitable for 12 V and 24 V on-board electrical systems
| Type | Philippi 3130-F12B-H7T1-W29AG3 |
|---|---|
| Switching Principle | Rocker switch, On/Off |
| Number of Poles | 2-pole |
| Rated Voltage | DC 30 V |
| Rated Current (Device) | 6 A |
| Rated Current Range | 0.1–16 A |
| Protection Function | Integrated overcurrent protection |
| Mounting Cutout | 26.3 × 34.2 mm |
| Device Width | 29.5 mm |
| Series | Philippi Series 200 |
philippi
Gewicht (ca.): 0.03 kg
Herstellerinformationen gemäß GPSR:
PHILIPPI ELEKTRISCHE SYSTEME GMBHNECKARAUE 19
71686 REMSECK
