Philippi BH 200 F
Regular price
€60,32
Regular price
Sale price
€60,32
Unit price
per
Tax included.
When reliability is paramount for your electrical system, the Philippi BH 200 F is the right choice. This professional battery master switch disconnects your electrical system safely and permanently – even under high current loads and in wet environments. Thanks to IP67 protection and robust relay technology, it is built for continuous use at sea.
Tip: When installing, ensure that the mounting cutout is exactly Ø 22 mm and that the connection cables on the M10 bolt are fastened with the correct torque – this prevents contact resistance and heat generation.
Couldn't load pickup availability
brand:
philippi
Availability:
Low stock
SKU:
OB-BB-600035200
Product group:
category:
electrical system
Regular price
€60,32
Regular price
Sale price
€60,32
- 200 A continuous current and 1000 A peak current for 30 seconds – safe even with high load peaks
- IP67 protection class – waterproof and therefore ideal for the humid on-board environment
- Switch lever removable in off position – simple theft protection and child safety lock
- Panel or flange mounting – flexible installation in the control cabinet or on the bulkhead
- Professional processing using proven relay technology for continuous use
| Type | Philippi BH 200 F |
|---|---|
| Continuous Current | 200 A |
| Peak Current | 500 A / 3 min |
| Short-time Peak Current | 1000 A / 30 s |
| Voltage | max. 32 V DC |
| Connection | M10 |
| Protection Class | IP67 |
| Mounting Hole Ø | 22 mm |
| Dimensions | Ø 55 × 105 mm |
| Mounting | Panel or Flange Mount |
| Special Feature | Switch lever removable in off position |
philippi
Gewicht (ca.): 0.15 kg
