Philippi 8345-C01A-U3T1-DB1A1B-100A
Regular price
€83,51
Regular price
Sale price
€83,51
Unit price
per
Tax included.
High-current protection that trips reliably even under the harshest conditions: The Philippi 8345-C01A-U3T1 is a single-pole hydraulic-magnetic circuit breaker with rocker switch actuation – designed for professional use on board and in marine technology. Thanks to its uninfluenceable trip-free mechanism, it reliably protects lines and consumers from overcurrent and short circuits, regardless of whether the lever is held manually.
Tip: For applications from 160 A, a version with a 38 mm device width is available – ensure sufficient space in the distributor during installation.
Couldn't load pickup availability
brand:
philippi
Availability:
Low stock
SKU:
OB-BB-183450100
Product group:
category:
electrical system
Regular price
€83,51
Regular price
Sale price
€83,51
- Hydraulic-magnetic trip principle – reliable switching behavior without thermal drift
- Trip-free mechanism – always trips in case of a fault, even if the toggle lever is held
- Suitable for DC 80 V and AC 240 V – flexible for use in DC and AC networks
- Rated current range 40–125 A – designed for high-current applications
- Threaded stud connection M6 – secure, maintenance-friendly cable connection
- Front mounting, compact device width 19 mm – space-saving in control panels and distributors
| Type | Philippi 8345-C01A-U3T1 |
|---|---|
| Poles | 1-pole |
| Tripping principle | Hydraulic-magnetic |
| Actuation | Toggle lever |
| Rated voltage DC | 80 V |
| Rated voltage AC | 240 V |
| Rated current range | 40–125 A |
| Connection | Threaded stud M6 |
| Mounting | Front mounting |
| Device width | 19 mm |
| Release | Trip-free mechanism |
philippi
Gewicht (ca.): 0.07 kg
