By Vetus
Maxwell verti. Windlass with capstan, RC10-8, 12V
Regular price
€1.985,02
Regular price
Sale price
€1.985,02
Unit price
per
Tax included.
Reliable hoisting, secure holding: The Maxwell RC10-8 is a mid-range vertical anchor windlass that handles 8mm chain and 14-16mm nylon rope in one unit. With 700 kg of pulling power and 1500 kg of static holding power, it makes anchoring on medium-sized yachts a relaxed routine task.
Switches and foot controls are not included and must be ordered separately - plan for this early in your installation planning.
Couldn't load pickup availability
Regular price
€1.985,02
Regular price
Sale price
€1.985,02
- 700 kg pulling power and 1500 kg static holding power – secure hold even in wind and current
- Processes 8mm short link chain and 14–16mm nylon rope – one device for both anchoring methods
- Chain speed 24 m/min, rope speed 20 m/min – quick hoisting without long waiting times
- Housing made of stainless steel and chrome-plated bronze – permanently corrosion-resistant in saltwater use
- Supplied complete with motor, gearbox and double relay – ready for immediate installation
| Type | RC10-8, vertical, without spill |
|---|---|
| Voltage | 12 V |
| Motor Power | 1000 W |
| Maximum Pull | 700 kg |
| Static Holding Power | 1500 kg |
| Chain Type | Short Link 8 mm (5/16") |
| Rope Size (Nylon) | 14–16 mm (9/16"–5/8") |
| Chain Speed | 24 m/min |
| Rope Speed | 20 m/min |
| Net Weight (Electric) | 19 kg |
| Housing Material | Stainless Steel and Chrome-Plated Bronze |
| Scope of Delivery | Motor, Gearbox, Dual Solenoid |
Vetus
Gewicht (ca.): 23.0 kg
