By Maxpower
MAXPOWER Bow Thruster CT80 24V Ø185
Regular price
€1.587,83
Regular price
Sale price
€1.587,83
Unit price
per
Tax included.
Maxpower's best-selling electric tunnel thruster – and for good reason: The CT80 delivers up to 80 kg of thrust, maneuvering your yacht with confidence even in tight harbors. Its compact 185 mm tunnel diameter makes it the first choice for motor and sailboats between 25 and 44 feet.
Tip: During installation, ensure the shortest possible, well-dimensioned cable run to the battery – even a voltage drop of 0.5 V can noticeably reduce thrust. Maxpower recommends a dedicated bow thruster battery or a powerful AGM battery bank.
Couldn't load pickup availability
Regular price
€1.587,83
Regular price
Sale price
€1.587,83
- 80 kg / 176 lbs of thrust (24 V) – powerful maneuvering even in wind and current
- Composite twin propeller for maximum efficiency with low power consumption
- Patented, maintenance-free drive train – no re-greasing, no oil changes
- Case-hardened spiral bevel gears for quiet, long-lasting operation
- Electronic control box with high-quality DC contactors for reliable safety functions
- Standard equipment on a variety of yachts – proven quality
| Model | CT80 |
|---|---|
| Voltage | 24 V |
| Power | 5.28 kW / 7.1 hp |
| Thrust | 80 kg / 176 lbs |
| Tunnel Diameter (D) | 185 mm |
| Propeller | Twin Propeller |
| Drive Train | Composite, patented, maintenance-free |
| Gears | Case-hardened, spiral bevel |
| Motor | Specially developed DC motor |
| Contactors | Custom-made DC contactors |
| Dimension A | 210 mm |
| Dimension B | 140 mm |
| Dimension C | 275 mm |
| Dimension D (Tunnel Ø) | 185 mm |
| Dimension E (Wall Thickness) | 6–7 mm |
| Weight | 15 kg |
| Suitable for | Motor and sailing yachts, 25–44 feet |
Maxpower
Gewicht (ca.): 15.5 kg
