By Mastervolt

Mastervolt MasterShunt 500 Czone

€345,14
€345,14
Tax included.

The core of your onboard power system: The MasterShunt 500 CZone monitors your battery bank with high precision and networks all relevant data – voltage, current, state of charge, and remaining runtime – with your chargers, inverters, and displays via a single MasterBus cable. Thanks to programmable events and an integrated real-time clock, it fully automates your system, extends battery life, and gives you complete control over your onboard energy balance at all times.

Tip: If the MasterShunt is installed directly near the batteries, the included busbar can be replaced with an ANL or T-fuse – saving space and cost. Fuse sold separately.
brand: Mastervolt
Availability: Low stock
SKU: OB-BB-77020115
Product group:
category:
electrical system
VetusVetus Odor Filter for Diesel 25mm 148x150x162mm
Vetus Geruchsfilter für Diesel 25mm 148x150x162mm
Typhoon Handschuhe Performance Finger offen Gr. YS
TyphoonTyphoon Gloves Performance Open Finger Size YS
Mastervolt MasterShunt 500 Czone
€345,14
€345,14

  • Triple communication via MasterBus, CZone and NMEA 2000 – seamless integration into existing onboard systems
  • Highly accurate SOC determination via digital shunt with battery-specific parameters – for realistic remaining runtime display
  • Full automation: Generator start at low battery level or warning at defined depth of discharge via programmable event
  • Flexible fuse type – ANL fuse (internal) or T-fuse (external) freely selectable, busbar included
  • Service mode prevents data loss of stored system data during maintenance
  • Scalable: Multiple MasterShunt units can be installed in parallel for higher current requirements

Model MasterShunt 500 CZone
Brand Mastervolt
Communication Interfaces MasterBus, CZone, NMEA 2000
Measured Values Voltage, current, state of charge (SOC), remaining runtime, historical data
Shunt Type Digital
Real-time Clock Integrated
Fuse Types ANL (internal) or T-fuse (external), each to be ordered separately
Special Feature Service mode to protect stored data during maintenance
Expandability Multiple units can be installed in parallel
DC Distribution Connection Via MasterConnect system
Housing Robust, with insulated DC connections
Main Fuse Not included – required separately
Applications Marine, mobile, industrial, infrastructure
