Mastervolt MASS GI 7 Isolation Transformer
No more galvanic corrosion at the berth: The Mastervolt MASS GI 7 galvanically isolates the shore power grid from the onboard electrical system, reliably protecting the underwater hull, propeller shaft, and all other metal parts from corrosion damage caused by stray current. With 7,000 VA of power and modern high-frequency technology, it is significantly lighter and more compact than classic low-frequency transformers – a real step forward for the demanding blue-water sailor or motorboat owner.
Tip: When planning a new installation, make sure to reserve space for a second MASS-GI device – by connecting them in parallel, the power can be easily doubled as onboard power consumption increases.
Couldn't load pickup availability
- Galvanic isolation between shore power and onboard electrical system – reliably protects metals from electrical corrosion
- High-frequency technology: up to 75% lighter and 60% smaller than conventional low-frequency transformers
- Integrated soft start reduces inrush current peaks and protects the onboard electrical system when connecting to shore power
- Wide-range input 90–255 V / 45–65 Hz – works in marinas worldwide, regardless of local mains voltage
- Parallel connection of multiple devices possible – easily scale performance as needed (e.g., 2 x 3.5 kW = 7 kW)
- LED display for load and overload, plus connection for remote control directly on the housing
| Model | MASS GI 7 |
|---|---|
| Rated power | 7,000 VA |
| Output current | 32 A @ 230 V AC |
| Input voltage | 90–255 V AC |
| Input frequency | 45–65 Hz |
| Output voltage | 90–255 V AC |
| Output frequency | 45–65 Hz |
| Technology | High-frequency isolation transformer |
| Soft start | Integrated |
| Parallel connection | Possible (multiple devices for higher capacity) |
| Display | LED for load and overload |
| Remote control | Possible |
| Housing | Aluminum, robust |
| Mounting position | Wall or floor, any position |
| Cable entry | PG glands with strain relief |
| Weight comparison | Up to 75% lighter than low-frequency transformers |
| Size comparison | Up to 60% smaller than low-frequency transformers |
Mastervolt
Gewicht (ca.): 10.0 kg
