Mastervolt MASS 24/100-C
Regular price
€3.034,30
Regular price
Sale price
€3.034,30
Unit price
per
Tax included.
When absolute reliability is paramount, the MASS 24/100-C is your choice: With 100 A charging current and an average Mean Time Between Failures (MTBF) of 180,000 hours, this professional Mastervolt device charges around the clock – even under the toughest conditions. The 3-stage IUoUo charging program supplies every battery type gently and efficiently, and the integrated MasterBus connection makes it a full-fledged part of your digital on-board network.
Tip: Connect a separate Mass remote control panel to keep an eye on charge status and alarm functions conveniently from the helm – especially practical on SOLAS-compliant vessels.
Couldn't load pickup availability
brand:
Mastervolt
Availability:
Low stock
SKU:
OB-BB-40021006
Product group:
category:
electrical system
Regular price
€3.034,30
Regular price
Sale price
€3.034,30
- 100 A charging current for large battery banks from 80 to 1,000 Ah and more
- 3-stage IUoUo characteristic – reliably recharges even completely discharged batteries
- Housing made of stainless steel and anodized aluminum – lightweight, robust, marine-grade
- Coated internal components permanently protect against moisture and condensation
- MasterBus compatible – central monitoring, configuration and remote control via cable
- GMDSS-compatible and DNV GL-certified – meets the highest maritime standards
| Type | 3-step battery charger |
|---|---|
| Charging characteristic | IUoUo |
| Outputs | 1 |
| Charge current | 100 A |
| Output voltage (Bulk) | 28.5 / 28.8 V |
| Output voltage (Float) | 26.5 / 27.6 V |
| Input voltage | 180–260 V AC, 50/60 Hz |
| Suitable battery capacities | 80–1,000 Ah and more |
| Battery types | All common types, incl. Lithium-Ion |
| Casing | Stainless steel and anodized aluminum |
| Internal protection | Coated components against moisture/condensation |
| Max. ambient temperature (full load) | 40 °C |
| MTBF | 180,000 hours |
| Temperature sensor | Integrated as standard |
| Bus system | MasterBus |
| Parallel connection | Possible |
| GMDSS compatible | Yes |
| Standards/Certificates | CE, ABYC A-31, IEC 60945, DNV GL, RRR, RMRS |
