By Mastervolt
Mastervolt BI 1202-S Battery Isolator
Regular price
€144,40
Regular price
Sale price
€144,40
Unit price
per
Tax included.
Two batteries, an alternator or a charger – and still no unwanted equalization between the banks: The Mastervolt BI 1202-S cleanly divides the charging current and keeps the starter and house batteries safely separated. The classic diode technology works maintenance-free and absolutely wear-free.
Tip: If you use a charger or regulator without automatic voltage drop compensation, manually adjust the output voltage by approx. 0.6 V – otherwise the batteries will be permanently slightly undercharged.
Couldn't load pickup availability
brand:
Mastervolt
Availability:
Low stock
SKU:
OB-BB-83012021
Product group:
category:
electrical system
Regular price
€144,40
Regular price
Sale price
€144,40
- Reliably separates two battery banks – no unwanted current feedback between banks
- Solid state with no moving parts – no wear, no maintenance
- Corrosion-resistant aluminum heatsink housing for durable onboard use
- Quick installation thanks to composite end plates with cable lugs and solid screw terminals
- Diode voltage drop (approx. 0.6 V) automatically compensable by Mastervolt Mass chargers and Alpha Pro regulators
- Compact, lightweight design for space-saving installation in the engine compartment or control cabinet
| Model | BI 1202-S |
|---|---|
| Type | Battery Isolator (Diode Splitter) |
| Technology | Classic Diode Technology |
| Number of Outputs | 2 (two battery banks) |
| Diode Voltage Drop | approx. 0.6 V |
| Housing / Cooling | Aluminum heatsink, corrosion-resistant |
| Casing | Plastic-encapsulated electronic components |
| Connection | Composite end plates with cable lugs, screw terminals with nuts and lock washers |
| Weight Range (BI series) | 580–1,300 g |
| Operating Voltage | 12 V / 24 V |
