By Johnson Pump
Johnson Viking COMPACT D38/D25 INDI
Regular price
€91,72
Regular price
Sale price
€91,72
Unit price
per
Tax included.
When space is limited but full pumping power is required: The Johnson Pump Viking Compact delivers first-class bilge performance in a compact housing. The single-chamber diaphragm pump is bulkhead-mounted – only the handle remains visible in the cabin or cockpit. Perfect for anyone looking for a powerful hand pump without compromising on installation space.
Tip: Before final screwing, rotate the inlet and outlet into the optimal position – this minimizes hose bends and maximizes pump performance.
Couldn't load pickup availability
brand:
Johnson Pump
Availability:
Low stock
SKU:
OB-BB-10-24800-01
Product group:
category:
equipment
Regular price
€91,72
Regular price
Sale price
€91,72
- Space-saving installation – pump body disappears into the bulkhead, only the handle remains visible
- Quick installation in minutes with only 4 screws and self-sealing gasket
- Supplied with KlickTite connectors in two sizes – 25 mm (1″) and 38 mm (1½″) included
- Inlets and outlets rotatable by 360° for maximum installation flexibility
- Up to 45 l/min flow rate (with Ø38 mm connection) for effective bilge pumping
- Robust nitrile rubber diaphragm and valves for long service life on board
| Housing | Polypropylene |
|---|---|
| Lid | ABS |
| Diaphragm | Nitrile rubber |
| Valves | Nitrile rubber (1 leaf valve and 1 tricuspid valve) |
| Wetted parts | Polypropylene, PA66GF30, Nitrile rubber |
| Max. suction height | 2.1 m |
| Max. delivery height | 1.2 m |
| Max. combined suction and delivery height | 3.3 m |
| Connections | KlickTite, Ø25 mm (1″) and Ø38 mm (1½″) – both included |
| Flow rate Ø25 mm (10 kPa, 45 strokes/min) | 34.5 l/min |
| Flow rate Ø38 mm (10 kPa, 45 strokes/min) | 45 l/min |
| Max. liquid temperature | +60 °C |
| Weight | 0.675 kg |
| Mounting | 4 screws, bulkhead mounted |
Johnson Pump
Gewicht (ca.): 1.07 kg
