By Johnson Pump

Johnson Impeller Pump F9B-3000 2'

€1.350,66
€1.350,66
Tax included.

Where standard pumps reach their limits, the F9B-3000 is just getting started. This high-performance impeller pump from Johnson Pump, with its separate bearing housing and robust mechanical seal, is designed for continuously hard work on board – and remains easy to maintain.

Tip: Keep the service kit 09-45581 and the impeller kit 09-802B as spares on board – so you are immediately ready for action during an impeller change at sea. An optional vacuum switch can be retrofitted to protect the pump from dry running.
brand: Johnson Pump
Availability: Low stock
SKU: OB-BB-10-13026-1
Product group:
category:
equipment
WhisperPowerWhisperPower - EXHAUST SWITCH SET
WhisperPower - ABGASSCHALTER-SATZ
Shakespeare N Typ Deckstecker & Buchse
ShakespeareShakespeare N Type Deck Plug & Socket
Johnson Impellerpumpe F9B-3000 2'
€1.350,66
€1.350,66

  • Separate bearing housing with permanently lubricated double ball bearings – significantly reduces wear and increases service life
  • Bronze housing and stainless steel shaft – corrosion-resistant even in continuous saltwater operation
  • Mechanical seal for reliable sealing even under high load
  • Versatile use: cooling water, bilge, deck wash, emergency and and fire pump
  • Wear parts quickly replaceable – service kit 09-45581 and impeller kit 09-802B available
  • Connection for optional vacuum switch already integrated

Model F9B-3000
Connection 2″ BSP
Drive Shaft Ø 17 mm
Length 282 mm
Width 120 mm
Height 157 mm
Weight 9.3 kg
Pump Housing Bronze
Shaft Stainless Steel
Seal Mechanical Seal
Cam Full or Partial Cam
Pedestal Cast Iron with Permanently Lubricated Double Ball Bearings
Connection (Thread Type) BSP or NPT
Impeller 09-802B-1 (alternative: 09-814B-9, on request)
Impeller Nitrile Available on request
Vacuum Switch Connection Present (accessory separate)
Service Kit 09-45581
Impeller Kit 09-802B

Johnson Pump

Gewicht (ca.): 8.56 kg
