By Johnson Pump

Johnson Aqua-Jet WPS 5.2 Pump 12V/2.8bar/20L

€304,56
€304,56
Tax included.

Running water on board without annoying hammering: The Johnson Pump Aqua-Jet WPS 5.2 is a five-chamber diaphragm pump that operates noticeably quieter and with less pulsation than conventional three or four-chamber pumps. With 20 l/min and a shut-off pressure of 2.8 bar, it reliably supplies the pressurized water system of small boats and recreational vehicles.

Tip: Always operate the pump with an upstream PumpProtector™ inlet filter (not included) and an accumulator tank – this significantly extends its lifespan and reduces the frequency of pressure switch cycles.
brand: Johnson Pump
Availability: Low stock
SKU: OB-BB-10-13406-07
Product group:
category:
equipment
prebitPrebit R1, D2W, CG, WH
Prebit R1
Webasto Schlauchverbinder gerade D60-60
WebastoWebasto Straight Hose Connector D60-60
Johnson Aqua-Jet WPS 5.2 Pumpe 12V/2
€304,56
€304,56

  • Five-chamber diaphragm technology significantly reduces noise and water pulsation compared to 3- or 4-chamber pumps
  • 20 l/min flow rate and 2.8 bar shut-off pressure for comfortable water pressure on board
  • Robust materials: Santoprene diaphragm, EPDM valves, polypropylene housing
  • Compact design – fits into tight installation spaces below deck
  • Standard ½″ BSP / ½″ hose and ½″ BSP / ¾″ hose connections for easy installation

Voltage 12 V
Motor Power 150 W
Flow Rate 20 l/min (5.2 GPM)
Shut-off Pressure (Standard) 2.8 bar (41 PSI)
Shut-off Pressure (Options) 2.1 bar (30 PSI) / 1.4 bar (20 PSI) on request
Number of Chambers 5
Diaphragm Material Santoprene
Valve Material EPDM
Housing Material Polypropylene (PP)
Fusing 15 A
Connection ½″ BSP / Hose ½″ and ½″ BSP / Hose ¾″ (NPT on request)
Dimensions (L × W × H) 240 × 214 × 110 mm
Weight 2 kg

Johnson Pump

Gewicht (ca.): 2.98 kg
