By Crosseven
Crosseven Copper Tubular Cable Lugs ø10.5 mm
Regular price
€5,18
Regular price
Sale price
€5,18
Unit price
per
Tax included.
Reliable cable termination for professional onboard use: These galvanized copper tubular cable lugs create a secure, low-resistance connection between the cable and the screw terminal. Whether it's the main circuit, motor connection, or battery wiring – the ø 8.4 mm hole size and 25 mm² cross-section make them a solid choice for high-performance onboard systems.
Tip: When crimping, ensure you use the correct crimping tool for 25 mm² – an incomplete crimp can increase contact resistance and lead to unwanted heat generation. Keep contact surfaces clean and grease-free before assembly.
Couldn't load pickup availability
brand:
Crosseven
Availability:
In stock
SKU:
OB-BB-P204535
Product group:
category:
electrical system
Regular price
€5,18
Regular price
Sale price
€5,18
- Galvanized copper – corrosion-resistant and permanently conductive, even in humid on-board air
- Suitable for cable cross-section 25 mm² – for main power and engine lines on board
- Hole size ø 8.4 mm – fits common M8 screw connections
- Processing by soldering or crimping – flexible to use depending on tools and preference
- High temperature resistance up to 200 °C – suitable for demanding applications
- 4 pieces in a set – immediately ready for typical on-board electrical projects
| Cable cross-section | 25 mm² |
|---|---|
| Hole size (bolt diameter) | ø 8.4 mm |
| Material | Copper, galvanized |
| Connection type | Soldering or crimping |
| Operating temperature | –180 °C to +200 °C |
| Scope of delivery | 4 pieces |
