Centa Coupling CF-AM-140 -K60-1.2
Regular price
€2.064,29
Regular price
Sale price
€2.064,29
Unit price
per
Tax included.
Less noise, less vibration, more comfort on board: The Centa CF-AM-140 is a highly elastic coupling that connects the gearbox and propeller shaft backlash-free, reliably dampening torsional vibrations, shocks, and structure-borne noise. The highly elastic rubber element with integrated thrust bearing transmits both torque and propeller thrust – and keeps your driveline permanently protected.
Tip: Before assembly, check whether the shaft and hub are thoroughly degreased and free of corrosion – this is the only way the clamping cone will sit with full friction grip and the specified torque range will be reliably achieved.
Couldn't load pickup availability
brand:
Ocean Birds
Availability:
Low stock
SKU:
OB-BB-CF-AM-140-K60-1- 60mm
Product group:
category:
Engine technology
Regular price
€2.064,29
Regular price
Sale price
€2.064,29
- Highly elastic rubber element perceptibly dampens torsional vibrations and shocks
- Interrupts structure-borne noise – for significantly quieter operation on board
- Compensates for axial, radial, and angular displacements in the drivetrain
- Backlash-free torque and thrust transmission via integrated thrust bearing
- High electrical insulation protects drive components from stray currents
- Supplied ready for installation – including clamping cone and integrated anti-rotation device
| Type | CF-AM-140-K60-1.2 |
|---|---|
| Design | Highly elastic coupling, type AM |
| Clamping cone | 60 mm H9 |
| Adapter | ZF63/68 |
| Adapter length | 115 mm |
| Elastic material | NR (Natural rubber) |
| Temperature range | −45 °C to +80 °C |
| Torque range (commercial) | 0.12 to 8 kNm |
| Torque range (pleasure) | 0.175 to 10 kNm |
| Transmission | Torque and propeller thrust |
| Electrical insulation | High |
| Delivery condition | Ready for installation, with integrated anti-rotation device |
| Application | Gearbox–propeller shaft, engine–gearbox, waterjet, Z-drive |
Ocean Birds
Gewicht (ca.): 20.0 kg
