By BukhPro
BUKH PRO Supra Hose Clamp 27 - 29 mm - W2
Regular price
€3,46
Regular price
Sale price
€3,46
Unit price
per
Tax included.
Securely clamped, even when things get salty: BUKH PRO's Supra hose clamp reliably seals hoses and pipes on board. With a band and housing made of W2 stainless steel (X6Cr 17), it is designed for use in humid and salty environments – and withstands pressures of up to 45 bar.
Tip: When installing, tighten the screw to a maximum of 10 Nm with a torque wrench – excessive torque can damage the hose material and impair the seal.
Couldn't load pickup availability
brand:
BukhPro
Availability:
In stock
SKU:
OB-BB-03019063
Product group:
category:
Engine technology
Regular price
€3,46
Regular price
Sale price
€3,46
- W2 (X6Cr 17, DIN 1.4016 / AISI 430) stainless steel band and bridge – permanently corrosion-resistant
- Tested salt spray resistance over 72 hours according to ASTM B-117
- Clamping range 27–29 mm – fits precisely on the intended hose diameter
- Maximum operating pressure 45 bar – for demanding piping systems on board
- M6 tightening screw with galvanized Cr3 bolt and nut – secure, controllable tightening torque up to 10 Nm
| Clamping range ø | 27–29 mm |
|---|---|
| Thread size (r) | M6 |
| Band width (e) | 8 mm |
| Screw length (a) | 18 + 02 mm |
| Bridge width (b) | 19.8 mm |
| Max. tightening torque | 10 Nm |
| Max. operating pressure | 45 bar |
| Band and carrier | Stainless steel W2, X6Cr 17, DIN 1.4016 / AISI 430 |
| Screw | 19 MnB4, Material no. 1.5523 (EN 10269) |
| Nut | Steel DC04 (EN 10130) / DC03-equivalent (DIN 1624) |
| Bolt & Nut surface | Galvanized Cr3 |
| Corrosion resistance | 72 hours salt spray according to ASTM B-117 (band, nut, bridge) |
| Version | Supra W2 |
