By BukhPro

BUKH PRO ASFA Hose Clamp 20 - 32 mm - W4

€4,09
€4,09
Tax included.

Reliable sealing, long-lasting hold: The BUKH PRO ASFA Hose Clamp W4 is a robust stainless steel clamp for hoses with a diameter range of 20 to 32 mm. Whether it's cooling water, fuel, or bilge lines – on board, it ensures a secure, vibration-resistant connection that won't give way under pressure.

Tip: Tighten the clamp to the specified maximum torque of 5.5 Nm – a torque screwdriver prevents overtightening and protects both the hose and the clamp.
brand: BukhPro
Availability: In stock
SKU: OB-BB-03014510
Product group:
category:
Engine technology
EpifanesEPIFANES Yacht Paint Light Oyster No. 25
EPIFANES Bootslack Light Oyster Nr.25
Hempel's Custom Marine Polish Renew 0
HempelHempel's Custom Marine Polish Renew 0.5
BUKH PRO ASFA Schlauchschelle 20 - 32 mm - W4
€4,09
€4,09

  • Wide clamping range of 20–32 mm for flexible applications with various hose sizes
  • Withstands pressures up to 40 bar – suitable for pressurized lines on board
  • W4 version made of corrosion-resistant stainless steel – ideal for the salty marine climate
  • Defined tightening torque of max. 5.5 Nm for controlled, secure installation
  • Compact band width (max. 11 mm) for tight installation situations in the engine compartment or bilge area

Clamping range (ø) 20–32 mm
Band length max. (L) 29.6 mm
Band thickness (S) 0.85 mm (+0.10)
Band height max. (h) 11 mm
Dimension a 12.2 mm (+0.3 / −0.1)
Dimension b max. 16.7 mm
Max. tightening torque 5.5 Nm
Max. operating pressure 40 bar
Version W4 (Stainless steel)
Manufacturer BUKH PRO / ASFA

BukhPro
