BUKH PRO ASFA Hose Clamp 130 - 150 mm - W4
Regular price
€15,39
Regular price
Sale price
€15,39
Unit price
per
Tax included.
Secure connections on board begin with the right clamp: The BUKH Pro ASFA hose clamp in W4 execution reliably holds hoses with a diameter range of 130–150 mm under pressure. Its precisely manufactured band geometry ensures even surface pressure – even in harsh marine use.
Tip: Tighten the clamp evenly with a torque wrench to a maximum of 7 Nm. Too much torque can damage the hose or deform the band – less is often more here.
Couldn't load pickup availability
brand:
BukhPro
Availability:
In stock
SKU:
OB-BB-03014633
Product group:
category:
Engine technology
Regular price
€15,39
Regular price
Sale price
€15,39
- Wide clamping range 130–150 mm for flexible applications on board
- Approved operating pressure up to 6 bar – suitable for pressurized hose connections
- Defined tightening torque of max. 7 Nm for safe, controlled tightening
- Flat band profile (h max. 11 mm) for space-saving installation even in confined spaces
- W4 version – entirely made of stainless steel for maximum corrosion resistance in saltwater environments
| Clamping range | 130–150 mm |
|---|---|
| Band width h max. | 11 mm |
| Band length L max. | 29.6 mm |
| Band thickness S | 0.85 mm (+0.10) |
| Dimension a | 12.2 mm (+0.3 / −0.1) |
| Dimension b max. | 16.7 mm |
| Max. tightening torque | 7 Nm |
| Max. operating pressure | 6 bar |
| Version | W4 (fully stainless steel) |
| Standard | ASFA |
