BUKH PRO ASFA Hose Clamp 110 - 130 mm - W4
Regular price
€14,49
Regular price
Sale price
€14,49
Unit price
per
Tax included.
Reliably seal where tightness matters: The BUKH PRO ASFA hose clamp in W4 design is the robust choice for hoses with a diameter range of 110 to 130 mm on board. With a maximum operating pressure of 8 bar, it sits securely – whether on cooling water, exhaust, or sanitary hoses.
Tip: Always tighten hose clamps with a calibrated torque wrench to the specified maximum torque of 7 Nm – this way you avoid leaks due to insufficient tightening torque and damage to the hose due to overtightening.
Couldn't load pickup availability
brand:
BukhPro
Availability:
In stock
SKU:
OB-BB-03014617
Product group:
category:
Engine technology
Regular price
€14,49
Regular price
Sale price
€14,49
- Clamping range 110–130 mm – fits common boat hoses in this diameter range
- Up to 8 bar operating pressure – reliably sealed even under system pressure
- Tightening torque max. 7 Nm – defined tightening without over-tightening
- W4 version – completely made of stainless steel for permanent corrosion protection in saltwater environments
- Compact band width of 11 mm – even where space is limited
| Clamping range (ø) | 110–130 mm |
|---|---|
| Band length max. (L) | 29.6 mm |
| Band thickness (S) | 0.85 mm (+0.10) |
| Band height max. (h) | 11 mm |
| Housing dimension a | 12.2 mm (+0.3 / −0.1) |
| Housing dimension b max. | 16.7 mm |
| Max. tightening torque | 7 Nm |
| Max. operating pressure | 8 bar |
| Version | W4 (completely stainless steel) |
| Standard series | ASFA |
