BEP Switch Panel DC 12V, 12-way, horizontal
Regular price
€568,64
Regular price
Sale price
€568,64
Unit price
per
Tax included.
Clear power distribution for demanding onboard installations: The BEP Switch Panel combines twelve circuit breakers in a flat, horizontally mountable unit. Red operating LEDs and green labeling LEDs show you at a glance which consumers are active - even in poor lighting conditions below deck.
According to the manufacturer, the labeling fields are not included - plan separate labeling strips or signs for your circuit designations. On request, the panel is also available in 24 V and as an AC variant with bipolar circuit breakers.
Couldn't load pickup availability
Regular price
€568,64
Regular price
Sale price
€568,64
- 12 circuit breakers in one unit – clearly structured power distribution for up to twelve onboard circuits
- Pre-assigned amperage (3 × 5 A, 4 × 10 A, 4 × 15 A, 1 × 25 A) – ready for immediate use
- Red operating LEDs and green labeling LEDs for instant status overview even in the dark
- Anti-corrosion-treated aluminum panel – permanently saltwater resistant and durable
- CE compliant – meets European requirements for onboard installations
- Horizontal mounting position – ideal for switch panels and compact installations
| Voltage | 12 V DC |
|---|---|
| Number of Circuits | 12 |
| Circuit Breaker Amperage | 3 × 5 A, 4 × 10 A, 4 × 15 A, 1 × 25 A |
| Poles | 1-pole |
| Mounting Position | Horizontal |
| Panel Material | Aluminum, anti-corrosion treated |
| Indicators | Red operating LEDs, green label LEDs |
| Certification | CE compliant |
| Dimensions | 115 × 351 × 65 mm |
| Labels | Not included |
| Optional Versions | 24 V DC; AC with bipolar circuit breakers (on request) |
BEP
Gewicht (ca.): 0.7 kg
