BEP Battery Switch HD 120A Switchable Reset

€76,20
€76,20
Tax included.

Reliable overcurrent protection for your electrical system: The BEP HD circuit breaker with 40 A automatically interrupts the circuit in case of overload and can be easily reset manually after tripping - no fuse replacement, no tools. Thanks to thermal tripping and a robust housing, it works reliably and permanently in harsh onboard electrical systems.

Tip: After a trip, always first check the cause of the overcurrent before resetting the switch - the visible indication mechanism helps you immediately recognize a tripped state.
brand: BEP
Availability: Low stock
SKU: OB-BB-185120P/DSP-BEP
Product group:
category:
electrical system
Victron EnergyVictron Argofet 100-2 Battery Isolator
Victron Argofet 100-2 Batterie Isolator
Typhoon Softshell Jacke 2.0 Gr.L - Grau/Grün
TyphoonTyphoon Softshell Jacket 2.0 Size L - Grey/Green
BEP Trennschalter HD 120A schaltbarer Reset
€76,20
€76,20

  • Thermal release mechanism – safely protects cables and loads from overcurrent
  • Switchable reset instead of single-use fuse – simply reset after tripping and continue operating
  • Visible tripped status – reset mechanism shows at a glance whether the switch has tripped
  • Breaking capacity 3,000 A – DC-safe even with high short-circuit currents
  • Wide temperature range – usable from -32 °C to +82 °C operating temperature
  • Housing made of UL-approved thermoset plastic (UL 94V-0) – flame-retardant and heat-resistant

Rated Current 40 A
Voltage Range 30 V DC
Interrupt Capacity 3,000 A
Trip Principle Thermal
Number of Poles Single Pole
Operating Temperature −32 °C to +82 °C
Storage Temperature −34 °C to +149 °C
Housing Material Thermoset plastic, flame retardant UL 94V-0, resistant up to 155 °C
Contact Material Tin-plated copper studs, brass rivets, stainless steel lock nuts
Mounting Panel mount; Series 184/185 also surface mount (F-base)
Sealing Sealed (Series 184 & 185) – suitable for engine compartment and bilge area
Indication Visible reset mechanism indicates tripped condition
Housing Approval UL 94V-0
