BEP ANL Fuse Holders, 35 - 300 A
When it comes to reliably protecting your on-board electronics, the BEP ANL fuse holder is the right choice. It is designed for use with ANL fuses from 35 to 300 A and protects demanding consumers such as inverters and battery chargers with extremely high interrupting capacity. The robust professional construction also withstands continuous full load – for installation professionals and ambitious DIY outfitters.
Tip: Mount the fuse holder as close to the battery as possible – the shorter the unprotected cable length, the better the protection of the entire on-board wiring. The ANL fuse is not included in the scope of delivery and must be selected separately to suit the protection of the respective consumer.
Couldn't load pickup availability
- High breaking capacity up to 6,000 A (ANL) – reliably protects even against severe short circuits
- Suitable for ANL fuses 35–300 A – covers a wide range of onboard consumers
- Durable construction – withstands even under maximum continuous load
- Rounded cable entries facilitate neat cable routing on board
- Ideal for inverters, battery chargers, and other power-intensive onboard devices
- Suitable for ANL fuses with 5/16" (8 mm) or 3/8" (10 mm) stud mounting
| Brand | BEP |
|---|---|
| Type | ANL Fuse Holder |
| Fuse Range | 35–300 A (ANL) |
| Maximum Interrupt Capacity | 6,000 A (ANL) |
| Suitable Fuse Bolts | 5/16" (8 mm) or 3/8" (10 mm) |
| Mounting Type | Surface Mount |
| Application | Inverters, Battery Chargers, High-Power On-Board Consumers |
| Scope of Delivery | Fuse Holder (without ANL Fuse) |
